Technical Specs

Customers have trusted Flamborough Tool & Mould Ltd. for efficient precision for over 20 years. We offer all the benefits of a small shop while offering the advanced capabilities and experience of a much larger one.

Our technical specifications are listed below. Please contact us if you have any questions.


CNC Mills

Makino SNC64 CNC High Speed Machining Centers (2 Units)

  • Maximum Spindle RPM – 20,000
  • Machine travel – 23.5” x 16.0” x 18”
  • Vacuum system for graphite electrode work

Kafo CNC Machining Center

  • Maximum Spindle RPM – 8,000
  • Machine travel – 40” x 21” x 22”

TOS FNG 40 CNC Machining Center

  • Maximum Spindle RPM – 2,500
  • Machine travel – 19” x 15.7” x 15.7”
  • CNC Rotary Table – 22” diameter
  • Vertical and horizontal head capabilities

EDMs

Charmilles F440 EDM Wire machine

  • Maximum part weight – 3,300 lbs
  • Machine travel – 21.6” x 13.7” x 15.7”
  • Maximum Taper – 30 Degrees

Charmilles 35P EDM Sinker

  • Maximum part weight – 1,100 lbs
  • Machine travel – 13.7” x 8.8” x 11.8”
  • 3 Maxi-mart manual EDM Sinkers

3 Maxi-mart manual EDM Sinkers


CNC Lathes

Super Max Slant Bed 10 HP

  • Bar Capacity – 2” diameter
  • 12 station turret
  • Maximum turning – 12” diameter x 18” long

Standard Modern Flat Bed

  • Maximum turning – 15” diameter x 36” long

Lifting Systems

  • 5 Ton over head crane system
  • 2 Ton Hoist

Manual Equipment

  • Ram and Turret Mills – 4 in total

Grinding Equipment

Surface Grinder

  • Table surface 10” x 20”
  • Distance spindle to table 18”

Cylindrical Grinder

  • Maximum swing 10”
  • Maximum distance between centers 24”

Welding Equipment

  • Miller Max star 200
  • Hobart Cyber-Tig 120 Series

Quality Assurance Processes & Tools

  • Statistical Process Control (SPC)
  • Statistical Quality Control (SQC)
  • Advanced Quality Planning (AQP)
  • Process Failure Model Effects Analysis (PFMEA)
  • Risk Analysis
  • Individual parts inspection reports
  • Computer networked checklists
